4L Capacity Planetary Ball Mill (4 x 1L) with optional Milling Jars - MSK-SFM-2-1
  • 4L Capacity Planetary Ball Mill (4 x 1L) with optional Milling Jars - MSK-SFM-2-1
  • 4L Capacity Planetary Ball Mill (4 x 1L) with optional Milling Jars - MSK-SFM-2-1
  • 4L Capacity Planetary Ball Mill (4 x 1L) with optional Milling Jars - MSK-SFM-2-1
  • 4L Capacity Planetary Ball Mill (4 x 1L) with optional Milling Jars - MSK-SFM-2-1
4L Capacity Planetary Ball Mill (4 x 1L) with optional Milling Jars - MSK-SFM-2-1

4L Capacity Planetary Ball Mill (4 x 1L) with optional Milling Jars - MSK-SFM-2-1

SKU: msk-sfm-2

Price: RFQ

Specifications

 MSK-SFM-2-1 is a Planetary Ball Mill with a total of 4L capacity). Various milling jars are optional from 500ml to 1000 ml. The product is extensively used in the fields of Geology, Mining, Metallurgy, Electronics, Construction Material, Ceramics, Chemical Engineering, Light Industry, Medicine, Environmental Protection, etc. SPECIFICATIONS Working Voltage 208 - 240V AC (single-phase), 50/60 Hz 750W power The 1500W transformer will be needed if operating at 110V 220V AC Power plug is not included. Please click here to order the plug). Speed control Digital controller by changing the frequency of three-phase AC motor Rotary Rate & Centrifugal acceleration: Main plate revolution: 35-335 rpm, Mixing tank self-rotation: 70- 670 rpm, Total Centrifugal acceleration:: 40 g Digital display Digital display of the speed in RPM/Hz Major platen's running time: 1- 3600 minutes adjustable Rest time: 1- 999 minutes adjustable anticlockwise rotation time: 1- 3600 minutes adjustable Suggested working time: 48 hours Max. MillingTank (Jar) The mill machine can carry 4 x 1000 ml jars. Please choose from the product bar The machine also can carry 4 x 500ml jars. Please click here to order Various 500ml jars The adaptor for a 500 ml jar is available Note: How to achieve finer or desired particles via ball mill is a research project, which is depended on the material to be mixed, grinding time and speed, combination of grinding jar and milling ball, etc. It is your responsibility to find the best milling procedure based on your material. Welcome you come to MTI lab at California to do a test before purchase Sieves 1 pcs 14 mesh for separating samples is included In order to mill efficiently, material particles shall be less than 14 mesh (1.12mm) Optional A larger ball mill with a 4x10L jar ( 40 L in total) is available upon request. PTFE and Stainless steel jars are available upon request Forced cold air to cool during milling is available at an extra cost Material for milling Max. input particle size: < 10mm for brittle material and < 3 mm for other materials Min output particle size: wet milling < 1 micron, and dry milling < 20 micron Compliance CE Certified NRTL certification is available at an extra cost


Working Voltage
  • 208 - 240V AC (single-phase), 50/60 Hz
  • 750W power
  • The 1500W transformer will be needed if operating at 110V
  • 220V AC Power plug is not included. Please click here to order the plug).
Speed control Digital controller by changing the frequency of three-phase AC motor
Rotary Rate &
Centrifugal acceleration:
  • Main plate revolution: 35-335 rpm,
  • Mixing tank self-rotation: 70- 670 rpm,
  • Total Centrifugal acceleration:: 40 g
Digital display
  • Digital display of the speed in RPM/Hz
  • Major platen's running time: 1- 3600 minutes adjustable
  • Rest time: 1- 999 minutes adjustable
  •  anticlockwise rotation time: 1- 3600 minutes adjustable
  • Suggested working time: 48 hours Max.
MillingTank (Jar)


  • The mill machine can carry 4 x 1000 ml jars. Please choose from the product bar
  • The machine also can carry 4 x 500ml jars. Please click here to order Various 500ml jars
  • The adaptor for a 500 ml jar is available
Note: How to achieve finer or desired particles via ball mill is a research project, which is depended on the material to be mixed, grinding time and speed, combination of grinding jar and milling ball, etc. It is your responsibility to find the best milling procedure based on your material. Welcome you come to MTI lab at California to do a test before purchase
Sieves
  • 1 pcs 14 mesh for separating samples is included
  • In order to mill efficiently, material particles shall be less than 14 mesh (1.12mm)
Optional
Material for milling
  • Max. input particle size: < 10mm for brittle material and < 3 mm for other materials
  • Min output particle size: wet milling < 1 micron, and dry milling < 20 micron
Compliance
  • CE Certified
  • NRTL certification is available at an extra cost
