SKU: cr2016-case

Price: RFQ

Description

 100 pcs of CR2016 button cells cases, made of stainless steel 304 or 316 with PP sealing O-ring

100 pcs of CR2016 button cells cases, made of stainless steel 304 or 316 with PP sealing O-ring
,
Specifications
Material
  • SS304 or SS316 , please choose from product option bar
Overall Dimensions
(Dia x Height)
  • 20mm x 1.6mm
Case Dimension
  • Cathode: O.D. = 20.0mm, I.D. = 19.4mm
  • Anode: O.D. = 19.3mm, I.D. = 16.8mm
Weight
  • 0.1 oz (2.0 grams)
Materials
  • Stainless Steel 304 or 316 case, please choose from the options bar.
  • Polypropylene Sealing Gasket
  • Max. working temperature: 80 °C
,
Options
please consider Al cladded CR2032 case, which can avoid electrolyte corrosion when the battery >4.5V
CR2016 coin cell case for in-situ XRD analysis
