Honeywell UL Approved Sensepoint Hydrogen Gas Detector - XCD-H2
  • Honeywell UL Approved Sensepoint Hydrogen Gas Detector - XCD-H2
Honeywell UL Approved Sensepoint Hydrogen Gas Detector - XCD-H2

Honeywell UL Approved Sensepoint Hydrogen Gas Detector - XCD-H2

SKU: xcdh2

Price: RFQ

Description

Honeywell XCD Sensepoint Gas Detector features a status LED, operation, and programmable fault relay. The alarm is set to 20% LEL of hydrogen.

SPECIFICATION

Power Input
  • 16-32 VDC
Features
  • Manufacturer: Honeywell Analytics
  • Flammable (catalytic or infrared) gas type.
  • Toxic and oxygen versions are available upon request.
  • Aluminum alloy explosion-proof housing
  • 4-20 mA signal output
  • Three programmable alarm relays are included.
  • Compliance: cULus, Class 1, Div 1, Group B, C, and D locations.
Tri-Color LCD

 A tri-color backlit LCD indicates the unit’s status.
A steady green backlight indicates normal operation, flashing yellow indicates the fault and flashing red indicates an alarm.
Application Note
  • All detectors are supplied pre-configured and include 3 programmable alarm relays, 1 programmable fault relay as well as an industry-standard 4-20mA output (sink or source selectable), and Modbus RTU communications.
  • It needs calibration every 6 months, and the Sensor needs replacement 2-3 years

Relay
  • The default alarm output is 20% LEL of hydrogen gas.
  • Relay controlled 1. Alarm Siren, and 2. Solenoid Valve for controlling Gas Inlet
Cable/Conduit Entries:
  • 3/4"NPT, two
Class/Division Hazardous Location
  • The detector is rated for Class I, Div 1.
Net Weight 11 lbs
Certification CE Certified and UL Approved
Warranty One-year limited warranty and lifetime support

OTHER TYPE Flammable,
toxic and oxygen gas detector
  • Supply Part Number: SPXCDULNRX for 0-100% LELmethane(CH4), and replacement (CH4) sensor (PN: SPXCDXSRXSS). Please email us for the quote.
Instruction


OPTIONAL PACKAGE

PART NO. Description
998-023-001 Calibration Gas Cylinder, Zero Air (20.9% oxygen, balance nitrogen)
XCDCOMBKIT Calibration Kit for XCD Combustibles Series
SPXCDXSFXSS The sensors last 2-3 years
