Description
- Single crystal TiO2 (Rutile) with Nb doped, wt0.5%
- Size: 10mm x 10mm x 0.5mm
- Orientation: (110)
- Purity: >99.99%
- Polish: one side EPI polished.
- Surface finish(RMS or Ra): <5A
Rutile ( TiO2) single crystal is one of the most suitable materials for spectral prisms and polarizing devices such as optical isolators and beam displacers because it has a large birefringence with a high refractive index. Compared to YVO4, TiO2 crystal is more stable chemically and physically. Our high quality rutile single crystal boule and polished components have been widely used for optical isolators and special prisms.
|
Typical Properties |
|
|
Crystal Structure |
Tetragonal a=4.5936 Å, c= 2.9582 Å , |
|
Growth Method |
Floating Zone |
|
Melting Point |
1840 oC |
|
Density |
4.26 g/cm3 |
|
Hardness |
Mohs 7 |
|
Specific Heat capacity |
0.17 ( 25 oC) Cal. / (g. Deg) |
|
Linear expansion Coefficient |
a: 7.14x10-6 c: 9.19x10-6 |
|
Refractive Index |
n0 = 2.47 ne = 2.73 at l = 1.3 mm |
|
Transmittance |
0.5- 4.5 mm |
|
Thermal optical Coefficient |
dh/dT: a: -0.72 x10-6/K c: -0.42x10-6/K |
|
Crystal boule dimension |
~25 mm dia x 35 mm length ( conical ) |
