Description
Specifications
|
Device Layer |
||
|
Size: |
|
10x10 |
|
Type/Dopant: |
|
N type/P-doped |
|
Orientation: |
|
<1-0-0>+/-0.5 degree |
|
Thickness: |
|
2.5±0.5µm |
|
Resistivity: |
|
1-4 ohm-cm |
|
Finish: |
Front Side Polished |
|
|
Buried Thermal Oxide: |
||
|
Thickness: |
|
1.0 um +/- 0.1 um |
|
Handle Wafers: |
||
|
Type/Dopant |
P type/B-doped |
|
|
Orientation |
|
<1-0-0>+/-0.5 degree |
|
Resistivity: |
10-20 ohm.cm |
|
|
Thickness: |
|
625 +/- 15 um |
|
Finish: |
|
As received (not polished) |
