Description
| IGBT Type | Individual IGBT |
|
Inverter Type |
Digital/Micro-controlled |
|
Output Type |
AC/DC TIG, DC Stick |
|
Voltage/phase |
208-240VAC, 1 and 3 phase, 50/60Hz |
|
I1MAX Current Rating |
@240V 1 Ph: 40A @240V 3 Ph: 31A |
|
I1EFF Current Rating |
@240V 1 Ph: 32A @240V 3 Ph: 16A |
|
OCV |
80V |
|
TIG Amps @ Rated Duty Cycle |
60% @ 250A, 100% @ 200A |
|
Stick Amps @ Rated Duty Cycle |
35% @ 200A, 60% 160A. 100% @ 130A |
|
TIG Output Range AC/DC |
10.2-20V/ 5-250A / 10.2-20V/ 5-250A |
|
TIG Output Range AC |
120V: 20-125A/10.8-15V |
|
Minimum Amp DC TIG Start |
5A |
|
Minimum Amp AC TIG Start |
5A |
|
TIG Start Type |
HF and Lift Start |
|
TIG Pulse |
Yes |
|
Standard AC/DC Pulse Frequency |
0.5 to 500 Hz |
|
Standard AC Pulse Frequency |
20 or 250 Hz |
|
Pulse Time On (Duty Cycle) |
Fixed/Preset |
|
Pulse Amp Range |
Fixed/Preset |
|
AC Frequency (Hz) |
20-250Hz |
|
AC Balance Range |
10-90% of Positive |
|
AC Wave Forms |
Advanced Square Wave |
|
Foot Pedal |
Optional |
|
Compliance |
|
|
Warranty |
3 years of limited manufacture warranty |
