SKU: msk-521

Price: RFQ

Description

Outstanding Features:

  • Auto-tension control.
  • Continuous fixed-length cutting mode
  • Minor adjustment at the cutting edge for the continuous cutting
  • Automatic tab welding and taping function is integrated with electrode cutting
  • PLC Touch screen control panel

MTI has granted the patent 201821974061.8 for the Automatic Slitting Machine MSK-520/MSK-521 series since September 2019.



Working Voltage
  • Single-phase 208~240VAC, 50/60Hz, 4 kW
Feeding Material Requirements
  • Electrode Roll: 6-80 mm (W), 50-800 mm (L), O.D. ≤ 400 mm, I.D. is 3" for loading on roller.
  • Tab Roll: 1.5 - 4 mm (W), 20-70 mm (L), O.D. ≤ 400 mm, I.D. is 80mm for loading on roller.
  • Protection Tape: 6- 20 mm (W), 6-80 mm (L), O.D. ≤ 200 mm, I.D. is 3" for loading on roller.
Winding Alignment
  • ±0.5 mm
Cutting Position Accuracy
  • ± 0.3mm
Tab Welding Tensile Force
  • >8 N
Tab length outside of trail
  • 6-30 mm
Part Lifetime
  • Lifetime for electrode blade: 500K times
  • Lifetime for tab blade: 500K times
  • Lifetime for welding head: 500K times
Compress Air Requirement
