500°C Convection Oven (1x1x1.2 meter 1200L) w/ Programmable Temperature Controller - KSL-500X-1200
  • 500°C Convection Oven (1x1x1.2 meter 1200L) w/ Programmable Temperature Controller - KSL-500X-1200
  • 500°C Convection Oven (1x1x1.2 meter 1200L) w/ Programmable Temperature Controller - KSL-500X-1200
500°C Convection Oven (1x1x1.2 meter 1200L) w/ Programmable Temperature Controller - KSL-500X-1200

500°C Convection Oven (1x1x1.2 meter 1200L) w/ Programmable Temperature Controller - KSL-500X-1200

SKU: ksl-500x-1200

Price: RFQ

Specifications

 KSL-500X-1200 is a large 500°C oven ( 1200 liters) with air convection and a programmable temperature controller to achieve a uniform temperature in the oven. It is a cost-effective industrial convection oven for a variety of laboratory applications, such as drying, debonding, and storage. Note: MTI performs test runs prior to shipment to ensure the quality of the oven. The heating chamber may have a slight brown-tinted color due to oxidation. SPECIFICATIONS: Power 208-240V AC, 3 phase, 50/60Hz 19 kW Working Temperature 450°C continuously 500°C < 30 minutes Heating Rate <7°C/min (0~300°C); <4°C/min (300~400°C); <0.5°C/min ( 400 - 500°C) Temperature Uniformity ± 2°C Temperature Controller 30 segments programmable digital temperature controller with +/- 1°C accuracy PID auto-tune function Over-temperature and thermocouple break protection RS485 PC communication is available at an extra cost. Chamber Stainless steel inner chamber with refractory fibrous thermal insulation Dimensions: 1000 mm (L) x 1000 mm (W) x 1200mm (H) ( 39"x39"x47"H Volume: 1200 L Exhaust port: 1" diameter on top of the oven 5 stainless steel shelves with a maximum loading of 8 kg per shelf. Thermocouple K type Compliance CE Certificate NRTL or CSA Certificate is available upon request at extra cost.

Power 208-240V AC, 3 phase, 50/60Hz
19 kW
Working Temperature  450°C continuously
500°C < 30 minutes
Heating Rate <7°C/min (0~300°C);
<4°C/min (300~400°C);
<0.5°C/min ( 400 - 500°C)
Temperature Uniformity ± 2°C
Temperature Controller
 30 segments programmable digital temperature controller with +/- 1°C accuracy
PID auto-tune function
Over-temperature and thermocouple break protection
RS485 PC communication is available at an extra cost.
Chamber
 Stainless steel inner chamber with refractory fibrous thermal insulation
Dimensions: 1000 mm (L) x 1000 mm (W) x 1200mm (H) ( 39"x39"x47"H
Volume: 1200 L
Exhaust port: 1" diameter on top of the oven
5 stainless steel shelves with a maximum loading of 8 kg per shelf.
Thermocouple K type
Compliance

 CE Certificate
NRTL or CSA Certificate is available upon request at extra cost.
