Compact Direct Read Flow Meter, 10-100 cc/min. with 1/8 NPT male fitting -FM100
  • Compact Direct Read Flow Meter, 10-100 cc/min. with 1/8 NPT male fitting -FM100
  • Compact Direct Read Flow Meter, 10-100 cc/min. with 1/8 NPT male fitting -FM100
Compact Direct Read Flow Meter, 10-100 cc/min. with 1/8 NPT male fitting -FM100

Compact Direct Read Flow Meter, 10-100 cc/min. with 1/8 NPT male fitting -FM100

SKU: fm100

Price: RFQ

Specifications

 Molded of tough polycarbonate plastic. Used to Indicate & Manually control Air or Gas flow. The compact flow meters are ideal for MTI tube furnaces . Easy to read design - The direct reading scales eliminate troublesome conversions. The scales are brushed aluminum, coated with epoxy and the graduations are on both sides of the indicating tube. Special integral flow guides stabilize the float throughout the range to keep it from hunting or wandering in the bore. The float is highly visible against a white background. Construction assures accuracy - All flow meter bodies are injection molded of tough, clear, shatter-proof polycarbonate plastic around a precision tapered pin. Critical internal diameter of the variable orifice tube is held within .0004". The result is accurate and repeatable readings. The backbone into which pipe thread inserts are welded to absorb piping torque. Precision metering valves of stainless steel valves permits precise flow adjustments. Specifiations: Item Number EQ-FM-100CC Range 10-100 cc/min Height Scale 4" Max. Temperature 54°C Max. Pressure 100 psi Caliber Dimension 1/8" BSPP connectors for up and down ports Accuracy 4% of full scale reading Application

Item Number

EQ-FM-100CC

Range

10-100 cc/min

Height Scale

 4"

Max. Temperature

54°C

Max. Pressure

100 psi

Caliber Dimension

1/8" BSPP connectors for up and down ports

Accuracy

4% of full scale reading

Application
