30L NTRL/CSA Certified Convection Oven (13x12x12, 250C) w/ Digital Temperature Controller - BPG-7032
  • 30L NTRL/CSA Certified Convection Oven (13x12x12, 250C) w/ Digital Temperature Controller - BPG-7032
  • 30L NTRL/CSA Certified Convection Oven (13x12x12, 250C) w/ Digital Temperature Controller - BPG-7032
30L NTRL/CSA Certified Convection Oven (13x12x12, 250C) w/ Digital Temperature Controller - BPG-7032

30L NTRL/CSA Certified Convection Oven (13x12x12, 250C) w/ Digital Temperature Controller - BPG-7032

SKU: bpg-7032

Price: RFQ

Specifications

 BPG-7032 is an NTRL Certified ( CSA Certified ) Forced Air Drying Oven with 30L capacity and 250°C Max. working temperature. This radiant warm wall heating system provides optimal uniformity and conserves chamber space for drying, curing, and plating applications. It is an ideal heating equipment for material R&D laboratories. SPECIFICATIONS: Working Voltage 110/220 VAC selectable Max. Power Consumption 850W Max. Operating Temperature 250°C Chamber Interior Material: 304 Stainless Steel Dimensions: 13"(L) x 12"(W) x 12"(H) (340 mm x 320 mm x 320 mm) Volume: 30L Dia. 5 mm Small window on the roof for additional thermocouple probe. 2 removable steel rack shelves, and max loading of 8 Kg per shelf Temperature Controller Single point setting temperature controller with +/- 1°C accuracy. Build-in over-temperature, thermocouple failure protection alarm. Build-in over-temperature, thermocouple failure protection alarm. Secondary over-temperature protection and auto power cut-off for the heating elements. Insulation 3" (7.6 cm) glass wool insulation prevents heat loss from the working chamber Ventilation Two hot air ventilation on the back of the oven One ventilation adjustment on the top of the oven One 5 mm Dia. slot on the top for an additional thermocouple probe Venting port 1.5'' diameter Door Glass Protected by Exclusive Polycarbonate Safety Shield Airtightness Enhanced by Silicone Door Gasket and Positive Latch Door Compliance CSA-US Certificated for both USA & Canada (for 110V version only) CE Certificated (for both 110V and 220V) Operation Manual ( for existing customers only ) Application Notes For accurate temperature recording, you shall calibrate the temperature by Temperature Calibrating Kit by yourselves, and set the temperature offset in the controller Please click here to learn How to calibrate the oven temperature and set temperature offset

Working Voltage 110/220 VAC selectable
Max. Power Consumption 850W
Max. Operating Temperature 250°C
Chamber
  • Interior Material: 304 Stainless Steel
  • Dimensions: 13"(L) x 12"(W) x 12"(H) (340 mm x 320 mm x 320 mm)
  • Volume: 30L
  • Dia. 5 mm Small window on the roof for additional thermocouple probe.
  • 2 removable steel rack shelves, and max loading of 8 Kg per shelf
Temperature Controller
  • Single point setting temperature controller with +/- 1°C accuracy. Build-in over-temperature, thermocouple failure protection alarm.
  • Build-in over-temperature, thermocouple failure protection alarm.
  • Secondary over-temperature protection and auto power cut-off for the heating elements.
Insulation 3" (7.6 cm) glass wool insulation prevents heat loss from the working chamber
Ventilation
  • Two hot air ventilation on the back of the oven
  • One ventilation adjustment on the top of the oven
  • One 5 mm Dia. slot on the top for an additional thermocouple probe
  • Venting port 1.5'' diameter
Door Glass Protected by Exclusive Polycarbonate Safety Shield
Airtightness Enhanced by Silicone Door Gasket and Positive Latch Door
Compliance
 CSA-US Certificated for both USA & Canada (for 110V version only)
 CE Certificated (for both 110V and 220V)
Operation Manual  ( for existing customers only )
