Description
| Input Voltage | DC24V (110/220VAC to 24VDC power adaptor included) |
| Swing Angle | ±23° |
| Swing Frequency | 1 - 20 swings/min |
| Number of Turns | 1 - 999 turns (for both clockwise and counterclockwise) |
| Rotating Speed | 1 -30rpm |
| Max. Cutting Diameter | Ø50mm |
| Sample Plate Dia. | Ø48mm |
| Controller Interface |
|
| Dimensions | Sample Fixture: 140mm(L) x 54mm(W) x 90mm(H) Control System: 205mm(L) x 250mm(W) x 160mm(H) |
| Weight | Sample Fixture: 1.65lbs Control System: 5.85lbs |
| Operation Video |  |
